Let Equals Equal Equals

11 minutes

Setting ariaDescribedByElements on a node silently fails when the target is in a different shadow root. The spec broke = to preserve encapsulation purity. This violates the Priority of Constituencies, harms AT users, and should be fixed immediately. Reference Target is complementary and welcome, but it is not a substitute for making imperative assignment work.

An equals sign broken in half, with a shadow cast behind it

The Bug

Here's a line of JavaScript that looks like it does something:

input.ariaDescribedByElements = [helpText];

You'd expect this to work. You're holding both nodes. You wrote the assignment. The browser accepted it without complaint.

But if helpText lives in a shadow root that isn't an ancestor of input's shadow root, the assignment is silently discarded. The getter returns null. No warning. No error. Assistive technology users get nothing.

Browser spec authors intentionally broke =.

Wait, What?

The spec for reflected element references defines a "scope" rule: the target element must be in the same DOM as the source, or in a parent DOM. Siblings, cousins, children -- all silently rejected.

So this works:

<div id="host">
  <template shadowrootmode="open">
    <input id="input">
    <span id="help">Help text</span>
  </template>
</div>
// Same shadow root: works
input.ariaDescribedByElements = [help];

And this works:

<span id="outer-help">Help text</span>
<div id="host">
  <template shadowrootmode="open">
    <input id="input">
  </template>
</div>
// Referencing "up" into lighter DOM: works
input.ariaDescribedByElements = [outerHelp];

But this doesn't:

<x-input>
  <template shadowrootmode="open">
    <input id="input">
  </template>
</x-input>
<x-tooltip>
  <template shadowrootmode="open">
    <span id="tip">Helpful description</span>
  </template>
</x-tooltip>
// Sibling shadow roots: silently fails
input.ariaDescribedByElements = [tip];
// getter returns [], AT sees nothing

Same API. Same syntax. Same intent. Different result, depending on tree position -- with no indication that anything went wrong.

I built a codepen demonstrating the inconsistency. The results are, as Steve Orvell put it, "confusing and seemingly inconsistent."

Why Does This Happen?

The restriction was added to prevent leaking shadow DOM internals. The concern: if you set el.ariaActiveDescendantElement to something inside a shadow root, then anyone with access to el could read that property and walk into the shadow tree.

Here's the scenario that worried spec engineers, paraphrased from Alice Boxhall's analysis:

// Component sets aria reference to internal element
lightEl.ariaActiveDescendantElement = shadowChild;

// Now any script can traverse into the shadow tree
lightEl.ariaActiveDescendantElement
       .parentElement
       .appendChild(document.createTextNode("surprise"));

This is a real concern. But the solution they chose -- silently discarding the setter -- trades an encapsulation worry for an accessibility failure. And the encapsulation worry has a straightforward fix (null out the getter while preserving the internal relationship for AT), while the accessibility failure has no fix at all from the developer's perspective, short of restructuring their entire DOM.

Moreover, the encapsulation concern is minor (most developers wouldn't care) while the accessibility failure is critical.

The Getter Problem Has Known Solutions

The spec discussion on whatwg/html#5401 explored multiple options for handling the getter when a referenced element is in a deeper shadow root:

  1. Return null from the getter, but keep the internal reference for AT -- the "attr-associated element" remains intact for the accessibility tree, even though JavaScript can't read it back.
  2. Retarget the reference to the shadow host, similar to how events retarget when crossing shadow boundaries. Alice Boxhall formalized this in WICG/aom#195, proposing that the getter retarget to the nearest visible host, with an opt-in API (getAttrAssociatedElement) to "undo" retargeting when the caller already has access to the relevant shadow root -- analogous to getComposedRanges() in the Selection API.
  3. Reference Target -- the component explicitly declares which internal element should be exposed.

Alice's comprehensive analysis of ARIA relationships and shadow DOM lays out these options in detail. Options 1 and 2 solve the encapsulation leak without breaking the setter. The spec authors chose something closer to option 0: discard everything silently.

Alice, who did much of the design work on ARIA element reflection, shared her frustration in a recent discussion:

I agree with Nolan's suggestion in the bug that developers should get a warning

supporting the cross-root case was indeed what we hoped the feature would enable; there was push-back from other standards engineers based on the reasoning I explained in the bug, so yeah it is now in something of a semi-broken state, which is very frustrating when so much work went into it

perhaps we would have been better off not trying to ship it at all

Imperative Means Intentional

When a developer writes:

input.ariaDescribedByElements = [someNode];

they already have both references. They already traversed whatever boundaries stood between them and those nodes. The assignment is an explicit, deliberate act.

As Steve Orvell (Lit team) noted after discussing with Chrome engineers:

this was done to hide shadow details, but I think there is room for push back since it's an imperative API and you need to be able to get access to all the nodes in question to use the API.

The encapsulation was already broken the moment you obtained the reference. Having = silently un-break it doesn't restore encapsulation. It just breaks accessibility.

Consider: why would anyone use the imperative API except to make a cross-root reference? If the elements were in the same scope, you'd use the aria-describedby content attribute with an ID. The entire purpose of the imperative API is to connect elements that attributes can't reach.

This is also how developers have handled cross root references in userland libraries for years, e.g. highcharts or leafmap mount points.

The Priority of Constituencies

The W3C's HTML Design Principles establish a binding hierarchy:

In case of conflict, consider users over authors over implementors over specifiers over theoretical purity.

The Web Platform Design Principles reaffirm:

User needs come before the needs of web page authors, which come before the needs of user agent implementors, which come before the needs of specification writers, which come before theoretical purity.

The current behavior inverts this. Spec engineers chose to protect encapsulation purity over user access to accessibility features. The constituency harmed (AT users) ranks highest in the hierarchy. The constituency served (spec authors concerned about theoretical encapsulation leaks) ranks lowest.

This isn't a close call. This is the worst possible violation of the highest principles of the HTML spec itself, perpetrated by spec authors, in the name of a theoretical purity that nobody asked for.

Brian Kardell argued (successfully) that the PoC is more of a guideline than a binding principle, and that even then, engineering resources should be taken into account. And regardless, the existence of the WHATWG is the tacit admission that browser vendors will do whatever they want, whenever they want. But even the most nuanced, least toothy read of the PoC puts this issue squarely in the center of the cross hairs. Theoretical spec purity must not win against real user needs.

"But What About Closed Shadow Roots?"

The encapsulation argument leans heavily on closed shadow roots. But closed shadow roots are vanishingly rare in practice:

  • Chrome UseCounters show open shadow DOM on ~17.5% of page loads vs closed on ~5.3%, but the closed figure is inflated by browser-internal UA shadow trees (<video>, <input>, etc.) and browser extensions.
  • No major web component framework defaults to closed shadow roots. Lit, Stencil, FAST, Angular, Svelte, Vue -- all default to open. Several don't even support closed mode.
  • Of 30,000+ Lit components on GitHub, roughly 5-10 use closed shadow roots.
  • eslint-plugin-wc ships a no-closed-shadow-root rule, warning that "closed shadow roots are very rarely used and can hinder development/interaction with an element."
  • Closed shadow roots provide no real security boundary. Browser vendors themselves ship extension APIs (dom.openOrClosedShadowRoot) to bypass them.

But even setting the data aside: if I have a reference to a node in a closed shadow root, I should be able to use it. Full stop. Having the reference means someone -- the component author, a framework, my own code -- already decided to share it. The encapsulation boundary was already crossed. The platform shouldn't second-guess that decision, especially not by silently breaking an accessibility feature.

The component author is a grown-up. If they expose a node reference, they accept that it might be used. And the user of assistive technology deserves to have that accessibility relationship work, regardless of what mode some attachShadow call used three layers up the DOM tree.

The spec is constraining a heavily-used imperative accessibility API to protect encapsulation guarantees that almost nobody uses, that provide no real security, and that actively harm the constituency the web platform is supposed to serve first: users.

For a deeper dive into the data, see my research on closed shadow root usage.

What Developers Actually Need

Here's a real pattern from the ARIA 1.1 Combobox example, implemented with web components:

<fancy-input>
  #shadow-root
    <input type="text">
</fancy-input>
<fancy-listbox>
  #shadow-root
    <ul role="listbox">
      <fancy-option>
        #shadow-root
          <li role="option">List item</li>
      </fancy-option>
    </ul>
</fancy-listbox>

The <input> needs aria-activedescendant pointing to the active <li>. These shadow roots are siblings. The imperative API was supposed to solve this. It doesn't.

As Nolan Lawson (Salesforce) documented in WICG/aom#192:

I guess for me the question is: "Why is it acceptable for elements in separate shadow roots to be linked with aria relationships, but only if those shadow roots are in a descendant-ancestor relationship (and only in one direction)?" To me, it's not clear what benefit this particular restriction provides.

This was filed in 2022. It remains open.

Reference Target Is Great. Also Not Enough.

Reference Target (WICG/webcomponents#1086) is a promising proposal that lets a custom element declare which internal element should be targeted by ARIA references. It's good work and I want it to ship.

But Reference Target is complementary, not a substitute:

  • Reference Target requires the component author to opt in. If a third-party component doesn't implement it, you're stuck.
  • Reference Target addresses the declarative case (aria-describedby attributes). The imperative case (ariaDescribedByElements = [...]) should work independently.
  • Reference Target is still in development. Phase 1 has open blockers. The imperative API exists today and is broken today.
  • = should mean =. Reference target doesn't fix that.

We should have both: Reference Target for the clean declarative path, and working imperative assignment for everything else.

The Fix

  1. Make the setter work. When a developer assigns el.ariaDescribedByElements = [node], persist the internal relationship for the accessibility tree regardless of shadow root topology.

  2. Null out the getter if needed. If the referenced element is in a deeper/sibling shadow root, return null from the JavaScript getter. This preserves encapsulation for scripts while letting AT see the relationship. This approach was explored in the spec discussion and is implementable.

  3. Warn, don't fail. At minimum, emit a console warning when an assignment is silently scoped away. Nolan Lawson suggested this and it's the bare minimum: developers need to know when their accessibility code doesn't do what they wrote.

  4. Ship Reference Target too. It's the right long-term solution for the declarative case. These are not competing proposals.

The Cost of Silence

Here's the real damage. A developer writes:

for (const node of descriptors) {
  el.ariaLabelledByElements = [
    ...el.ariaLabelledByElements,
    node,
  ];
}

This loop looks obvious. It's not. Some iterations silently succeed, others silently fail, depending on the shadow root positions of elements that the developer may not even control. Only extensive manual testing with a screen reader will reveal the failure. Many developers won't do that testing. AT users will pay the price.

When a platform API silently discards accessibility relationships, it isn't protecting users from encapsulation violations. It's protecting spec purity from users.

That's backwards. Fix it.
